DB-WXD3-12 Trimmer potentiometer

Brand: HW
MOQ: 500 Pieces
Delivery time: 15 Day
Product Details
DESCRIPTION: DB-WXD3-12 Trimmer potentiometer
HOWANG P/N: DB-WXD3-12
ELECTRICAL CHARACTERISTIC 1. Total resistance: 100Ω-147KΩ
2. Total resistance Tolerance: ±5%
3. Resistance taper: B TAPER(Linear)
4.Insulation resistance: More than 500 MΩ at DC500V
5.Rated Power : 1W
MECHANICAL CHARACTERISTIC 1.Total Rotation angle:1800°±10°
2. Rotational Torque: Less than 36mN.m
4. Rotation Stopper Strength:Less than 55mN.m
5. Rotational Life: (Standard Life) 10,000 cycles



xxxxxx











This is an introduction about HOWANG Wire-wound potentiometer series. We have many sizes and specifications for choice. Please be free to leave us a message below or contact us to learn more technical and price details. Our team will quickly respond within 24 hours.
